Page 38 - EgePanel Katalog Yeni

Boyut Standardı Ebatlar
Dimension Standart Size 10 mm - 200 mm
TS EN 10034
Boy
Kalite Standardı Length 4 - 18 metre
HEB Quality Standart Üretim Standartları ve Çelik Kaliteleri
TS EN 10025-1 / 2

Production Standards and Steel Grades

Üretim Standartları Çelik Kaliteleri

EN 10058 / DIN 59200
ASTM A6 / A 6M

Birim Yüzey Statik Parametreler Çap (mm) Diameter mt / kg
Kesit
Boyutlar ve Toleranslar Kütle Alanı Static Parameters
Alanı 12 x 3 mm 0,283
Unit
Anma Ölçüsü Section Mass Surface
Area
Nominal Size x-x y-y 16 x 3 mm 0,377
HE.B Silme Demir - LAMA Grubu Flat Iron - Bars
F G S I W İ W İ 18 x 3 mm 0,424
h b t r x x y y 20 x 3 mm 0,471
2
(cm ) 2 (kg/m) (m /m) cm 4 cm 3 cm cm 3 cm
120 120 +3/-2 120 +4/-2 6,5 ±0,7 11,0 +2,5/-1,5 12,0 34,0 26,7 0,686 864 144 52,9 3,06 20 x 4 mm 0,628
140 140 +3/-2 140 +4/-2 7,0 ±1,0 12,0 +2,5/-1,5 12,0 43,0 33,7 0,805 1510 216 5,93 78,5 3,58 20 x 5 mm 0,785
160 160 +3/-2 160 +4/-2 8,0 ±1,0 13,0 +2,5/-1,5 15,0 54,3 42,6 0,918 2490 311 6,78 111,0 4,05 25 x 5 mm 0,981
180 180 +3/-2 180 +4/-2 8,5 ±1,0 14,0 +2,5/-1,5 15,0 65,3 51,2 1,04 3830 426 7,66 151,0 4,57 30 x 3 mm 0,706
200 200 +4/-2 200 +4/-2 9,0 ±1,0 15,0 +2,5/-1,5 18,0 78,1 61,3 1,15 5700 570 8,54 200,0 5,07 30 x 5 mm 1,178
220 220 +4/-2 220 +4/-4 9,5 ±1,0 16,0 +2,5/-1,5 18,0 91,0 71,5 1,27 8090 736 9,43 258,0 5,59 35 x 5 mm 1,370
240 240 +4/-2 240 +4/-4 10,0 ±1,5 17,0 +2,5/-1,5 21,0 106,0 83,2 1,38 11260 938 10,3 327,0 6,08 40 x 5 mm 1,570
260 260 +4/-2 260 +4/-4 10,0 ±1,5 17,5 +2,5/-1,5 24,0 118,0 93,0 1,50 14920 1150 11,2 395,0 6,58 50 x 5 mm 1,963
280 280 +4/-2 280 +4/-4 10,5 ±1,5 18,0 +2,5/-1,5 24,0 131,0 103,0 1,62 19270 1380 12,1 421,0 7,09 60 x 5 mm 2,356
300 300 +4/-2 300 +4/-4 11,0 ±1,5 19,0 +2,5/-1,5 27,0 149,0 117,0 1,73 25170 1680 13,0 571,0 7,58 70 x 5 mm 2,748
320 320 +4/-2 300 +4/-4 11,5 ±1,5 20,5 +2,5/-2,0 27,0 161,0 127,0 1,77 30820 1930 13,8 616,0 7,57 80 x 5 mm 3,140
340 340 +4/-2 300 +4/-4 12 ±1,5 21,5 +2,5/-2,0 27,0 171,0 134,0 1,81 36660 2160 14,6 646,0 7,53 100 x 5 mm 3,925
360 360 +4/-2 300 +4/-4 12,5 ±1,5 22,5 +2,5/-2,0 27,0 181,0 142,0 1,85 43190 2400 15,5 676,0 7,49
400 400 +4/-2 300 +4/-4 13,5 ±1,5 24 +2,5/-2,0 27,0 198,0 155,0 1,93 57680 2880 17,1 721,0 7,40
450 450 +5/-3 300 +4/-4 14 ±1,5 26 +2,5/-2,0 27,0 218,0 171,0 2,03 79890 3550 19,1 781,0 7,33
500 500 +5/-3 300 +4/-4 14,5 ±1,5 28 +2,5/-2,0 27,0 239,0 187,0 2,12 107200 4290 21,2 842,0 7,27
